Liv Devote Advanced 0

Liv Devote Advanced 0
  • Color: Tiger Red
$4,500.00
Color: Tiger Red
Size: Select size
Wheel Size: 700c
Please select options Unavailable
Sorry, this item is currently not available. Please call us at 504-828-1862 check back.

Details

The Devote Advanced is your go-to for going fast, wherever the gravel muse may call you. Balancing speed and ruggedness, this versatile bike is ready for race day, rest day, and multi-day adventures.

Ultralight Agility
An ultralight Advanced-grade composite frame and fork make for snappy acceleration, while internal cable routing streamlines your cockpit and makes room for your must-have accessories. And the redesigned geometry puts you in a more aggressive position, increases traction and stability, and allows more control at speed and on descents.

Superior Compliance and Control
The Contact XR D-Fuse handlebar features a 5-degree back sweep and flare drop for comfortable and ergonomic grip. Select models also feature the Contact D-Fuse seatpost and one is equipped with a dropper post. Or swap out for your preferred set-up. These proprietary D-Fuse components absorb bumps and reduce vibrations, ensuring less fatigue and more fun on those epic rides.

Unmatched Versatility
Adapt to the route with the flip chip – dropout, which lets you adjust your wheelbase length and rear-wheel tire clearance. Go shorter for responsive handling and quick acceleration. Go longer for added stability plus clearance for larger tires and extra traction. Plus, the integrated down tube storage lets you stash a multi-tool or extra fuel, so nothing’s slowing you down.

Geometry Chart:
X-SmallSmallMediumLarge
Seat Tube Length (inch) 15.4 16.5 18.3 19.7
Seat Tube Angle 74.5° | 74.4° 74.5° | 74.4° 74.5° | 74.4° 74.5° | 74.4°
Top Tube Length (inch) 20.7 | 20.7 21.1 | 21.1 21.5 | 21.5 21.9 | 21.9
Head Tube Length (inch) 3.5 4.3 5.5 6.3
Head Tube Angle 70.0° | 69.9° 70.5° | 70.4° 71.0° | 70.9° 71.0° | 70.9°
Fork Rake (inch) 2 2 2 2
Trail (inch) 3.1 | 3.2 3 | 3.1 2.8 | 3 2.8 | 3
Wheelbase (inch) 39.8 | 40.2 40.1 | 40.5 40.4 | 40.8 41.1 | 41.4
Chain Stay Length (inch) 16.7 | 17.1 16.7 | 17.1 16.7 | 17.1 16.9 | 17.3
Bottom Bracket Drop (inch) 3.1 | 3.2 3.1 | 3.2 3.1 | 3.2 3.1 | 3.2
Stack (inch) 20.6 | 20.6 21.4 | 21.5 22.6 | 22.6 23.3 | 23.4
Reach (inch) 15 | 14.9 15.1 | 15.1 15.2 | 15.2 15.4 | 15.3
Stand Over Height (inch) 26.8 | 27.1 27.9 | 28.1 29.4 | 29.7 30.7 | 30.9
Handlebar Width (inch) 15.7 15.7 16.5 16.5
Stem Length (inch) 2 2.4 2.8 3.1
Crank Length (inch) 6.5 6.7 6.8 6.8
Wheel Size 700 700 700 700
Sizes:
SizeHeight
Small 4'11"-5'4"
Medium 5'2"-5'7"
Large 5'5"-5'9"
X-Large 5'7"-5'11"

Specs

Frame Advanced-grade composite, 12x142mm thru-axle, flat mount disc, flip chip – dropout, integrated down tube storage, integrated cable routing
Fork Advanced-grade composite, full-composite OverDrive steerer, stainless steel bearings, 12mm thru-axle, flat mount disc
Rims Giant CXR 2 Carbon Disc WheelSystem, [F] 35mm, [R] 35mm
Hubs [F] Giant alloy, CenterLock, 12mm thru-axle [R] Giant AR alloy, 3-pawl driver, CenterLock, 12mm thru-axle
Spokes Sapim Sprint
Tires CADEX AR, 700x40c, tubeless
Bottom Bracket Shimano, press fit
Crankset Shimano GRX FC-RX820, 31/48 XS/ S: 170mm, M/L: 172.5mm
Shifters Shimano GRX RX-820, 2x12
Front Derailleur Shimano GRX RX-820
Rear Derailleur Shimano GRX RX-820
Cassette/Freewheel Shimano CS-HG710, 12-speed, 11x36
Chain KMC X12L-1
Brakes Shimano GRX RX-820 hydraulic, Shimano RT-70 rotors [F]160mm, [R]160mm
Brake Levers Shimano GRX RX-820 hydraulic
Handlebars Giant Contact XR D-Fuse, 31.8mm, 5-degree back sweep, flare drop, alloy XS: 400mm, S: 400mm, M: 420mm, L: 420mm
Tape/Grips Liv All Condition
Stem Giant Contact AeroLight, -10 degree, alloy XS: 50mm, S: 60mm, M: 70mm, L: 80mm
Seatpost Giant Contact SL D-Fuse, composite, -5/+15mm offset
Pedals Sold Separately
Saddle Liv Approach
Extras 53mm max tire size in long flip chip position, 45mm max tire size in short flip chip position, tubeless prepared, ISC clamp, integrated down tube storage bag

* Subject to change without notice.

Part Numbers

Option UPC MPN
Tiger Red / X-Small / 700c 4712878981751 1032005103
Tiger Red / Small / 700c 4712878981768 1032005104
Tiger Red / Medium / 700c 4712878981775 1032005105
